Detailed specifications

1. 2.54mm Pitch

2. Connection method: Horizontal and vertical

3. Pins number : 4-20pos

4. The guiding design brings superior fit (guiding amount: ± 1.6mm)

5. The unique contact design enhances the mating performance

6. Supports 8 Gbps PAM4 performance

Detailed specifications

1. 0.6mm Pitch

2. Connection method: Horizontal

3. Pin number : 74pos

4. The guiding design brings superior fit (guiding amount: ± 1.6mm)

5. The unique contact design enhances the mating performance

6. Supports 14 Gbps PAM4 performance

Detailed specifications

1. 0.8mm Pitch

2. Connection method: Horizontal

3. Pin number : 10-200pos

4. The guiding design brings superior fit (guiding amount: ± 1.6mm)

5. The unique terminal contact design enhances the mating performance

6. Supports 14 Gbps PAM4 performance

Detailed specifications

1. 0.80 mm Pitch (0.315 inches)

2. 100-ohm differential signal wiring

3. 30 AWG dual-axis wire

4. 98-needle double-row system

5. Standard metal locking system
