Card Edge Series
61C1 HSEC8 0.80mm Card Edge SLOT Connector series
1.Applicable to PCB1.60mm
2.28 Gbps PAM4 performance
3. The signal terminal can pass current value: 1A/core
4. Choice of orientation and design supports multiple applications
5. Larger guide design facilitates fitting
6. Number of PINs: 10~200pos (any combination)
61C6 0.80mm Card Edge SLOT Connector series
1.Applicable to PCB1.60mm
2.28 Gbps PAM4 performance
3. The signal terminal can pass current value: 1A/core
4. Choice of orientation and design supports multiple applications
5. Larger guide design facilitates fitting
6. Number of PINs: 20pos (any combination)
61D2 HSEC1 1.00mm Card Edge SLOT Connector series
1.Applicable to PCB1.60mm
2.28 Gbps PAM4 performance
3. The signal terminal can pass current value: 1A/core
4. Choice of orientation and design supports multiple applications
5. Larger guide design facilitates fitting
6. Number of PINs: 10~200pos (any combination)
61F2 MECF 1.27mm Card Edge SLOT Connector series
1.Applicable to PCB1.60mm
2.28 Gbps PAM4 performance
3. The signal terminal can pass current value: 1A/core
4. Choice of orientation and design supports multiple applications
5. Larger guide design facilitates fitting
6. Number of PINs: 10~200pos (any combination)
61G1 MEC2 2.00mm Card Edge SLOT Connector series
1.Applicable to PCB1.60mm
2.28 Gbps PAM4 performance
3. The signal terminal can pass current value: 3A/core
4. Choice of orientation and design supports multiple applications
5. Larger guide design facilitates fitting
6. Number of PINs: 10~200pos (any combination)
61H1 2.54mm Card Edge SLOT Connector series
1.Applicable to PCB board thickness 1.60mm
2. Current value that can pass through the terminal: 12A/PIN(within a temperature of 30 degrees)
3. Choice of orientation and design supports multiple applications
4. Larger guide design facilitates insertion
5. Number of cores: 04 to 100 even-numbered PINs (complete models)
6. Plastic can withstand temperatures up to 270 degrees, with a maximum working temperature of 140 degrees.
61H2 2.54mm Card Edge SLOT Connector series
1Applicable to PCB board thickness 1.60mm
2. Current value that can pass through the terminal: 6A/pin (within a temperature of 30 degrees)
3. Choice of orientation and design supports multiple applications
4. Larger guide design facilitates insertion
5. Number of cores: 04 to 100 even-numbered PINs (complete models)
6. Plastic can withstand a temperature of 270 degrees, with a maximum working temperature of 125 degrees.
61H3 2.54mm Card Edge SLOT Connector series
1.Applicable to PCB board thickness 1.60mm
2. Current value that can pass through the terminal: 6A/pin (within a temperature of 30 degrees)
3. Choice of orientation and design supports multiple applications
4. Larger guide design facilitates insertion
5. Number of cores: 04 to 100 even-numbered PINs (complete models)
6. Plastic can withstand a temperature of 270 degrees, with a maximum working temperature of 125 degrees.
61H8 2.54mm Ageing Card Edge SLOT Connector series
1. Applicable PCB thickness 1.60mm
2. Current value that can pass through the terminal: 6A/pin (within a temperature of 30 degrees)
3. Choice of orientation and design supports multiple applications
4. Larger guide design facilitates insertion
5. Number of cores: 04 to 100 even-numbered PINs (complete models)
6. Plastic can withstand a temperature of 270 degrees, with a maximum working temperature of 125 degrees.
7. Resistant to plugging and unplugging 20,000 times+
61H3 SERIES 2.54 Gold finger slot plastic height 9.0mm 06-100PIN full series
Detailed specifications
1. Applicable PCB thickness: 1.60mm
2. Current capacity :3A /pin (within 30 degrees celsius )
3. The selection of direction and design supports multiple applications
4. The larger guiding design facilitates insertion
5. Number of cores: 04 to 100 even-numbered pins (complete range of models)
6. The reliable contact structure can make the contact more stable and reduce the impedance
7. Withstanding temperature : 270 degrees celsius
8. Connection method: straight, bent, SMT
61D3 SERIES 1.0mm Pitch gold finger slot SMT connector high-temperature resistant
Detailed specifications
1. Applicable PCB thickness: 1.60mm
2. 28 Gbps PAM4 performance
3. Current capacity for signal terminal : 1A /pin
4. The selection of direction and design supports multiple applications
5. The larger guiding design facilitates the fit
6. Number of pins : 10, 20, 30, 40, 50, 60, 70, 80, 100, 120, 140, 150, 160, 180, 200 POS
7. Compatible with the entire samtec HSEC1 series
8. Contact finish : Gold plating
9. Plastic material: LCP
10. Production cycle: 10 to 15 days
11. Packaging method: tape and reel
61F6 SERIES 1.27mm pitch gold finger slot MECF arbitrary combination 4-200PIN SMT surface mount seri
Detailed specifications
1. Applicable PCB thickness: 1.60mm
2. 14 Gbps PAM4 performance
3. Current capacity for signal pin : 2A /pin
4. The selection of direction and design supports multiple applications
5. The larger guiding design facilitates the fit
6. Number of pins : 06 to 200 pins can be freely selected
7. Contact finish : Gold plating
8. Plastic material: LCP
9. Production cycle: 15-20 days
10. Packaging method: tape and reel
61H6 SERIES 2.54mm pitch Gold finger slot connector plastic raised H=14.25 06-100Pin bent plug
Detailed specifications
1. Applicable PCB thickness: 1.60mm
2. Current capacity : 12A/pin (within 30 degrees Celsius)
3. The selection of direction and design supports multiple applications
4. The larger guiding design facilitates insertion
5. Number of pins : 04 to 100 even-numbered pins (complete range of models)
6. The reliable contact structure can make the contact more stable and reduce the impedance
7. Withstanding temperature: 270 degrees Celsius
8. Connection method: Bent insertion
9. Contact finish : Gold plating
10. Plastic material: LCP
11. Production cycle: 2-3 weeks
12. Packaging method: Tray packaging
61F1 SERIES 1.27mm Pitch gold finger slot connector, 12-pin 180-degree straight insertion, gold-pla
Detailed specifications
1. Applicable PCB thickness: 1.20mm
2. Current capacity : 1A/ pin (within 30 degrees celsius )
3. The selection of direction and design supports multiple applications
4. The larger guiding design facilitates insertion
5. Number of pins : 12, 14, 20 pins
6. The reliable dual-contact structure enables more stable contact and lower impedance
7. Withstanding temperature : 270 degrees celsius , Working temperature : 125 degrees celsius
8. The top choice in the sweeper industry
9. Contact finish : Gold plating
10. Plastic material: LCP
11. Production cycle: 10 to 15 days
12. Packaging method: Blister packaging
61F8 1.27 double-layer contact gold finger slot connector with 10 to 200 pins for arbitrary selectio
Detailed specifications
1. Applicable PCB board thicknesses :2.00 to 2.40mm
2. 4 Gbps PAM4 performance
3. Current capacity for signal terminal : 5A/pin
4. The selection of direction and design supports multiple applications
5. The larger guiding design facilitates the fit
6. Number of pins: 6 to 200 pins, can be freely selected
7. Contact finish : Gold plating 10u
8. Plastic material: PA9T
9. Production cycle: 15-20 days
10. Packaging method: Tray packaging
61H5 SERIES 2.54mm pitch Gold finger slot power connector, 50 pins, plastic raised H=26.75, 90° bent
Detailed specifications
1. Applicable PCB thickness: 1.60mm
2. Current capacity : 12A/pin (within 30 degrees Celsius)
3. The selection of direction and design supports multiple applications
4. The larger guiding design facilitates insertion
5. Number of cores: 04 to 100 even-numbered pins (complete range of models)
6. The reliable contact structure can make the contact more stable and reduce the impedance
7. Withstanding temperature of plastic : 270 degrees Celsius
8. Connection method: Bent insertion
9. Contact finish : Gold plating
10. Plastic material: LCP
11. Production cycle: 2-3 weeks
12. Packaging method: Tray packaging
61F9 gold finger slot, 90-degree SMT clamping type, full series, 10 to 300 pins, freely selectable,
Detailed specifications
1. Applicable PCB board thickness: 1.60 to 2.00mm
2. 4 Gbps PAM4 performance
3. Signal pin :3A/pin
4. The selection of direction and design supports multiple applications
5. The larger guiding design facilitates the fit
6. Number of pins : 06 to 300 pins, freely selected
7. Contact finish : Gold plating
8. Plastic material: PA9T
9. Production cycle: 15-20 days
10. Packaging method: Tray packaging
Total 1 page 20 records
